Round, oval and elliptical precision tube in 0.6 mm to 3.2 mm wall
Cold rolled precision tubing is engineered for tight-tolerance, clean-surfaced applications where the tube is formed, bent or plated downstream rather than simply installed.
The range covers cold-rolled light-wall round tube (0.60 mm to 2.00 mm), precision ERW round tube for heavier mechanical duty (0.80 mm to 3.20 mm), and specialized oval and elliptical profiles. The surface is finished to take chrome plating directly, and the steel chemistry is selected so it bends and draws without splitting at the weld.
Round tube complies with BS 1717:1983, BS EN 10305-3:2010, EN 10296-1:2003 and ASTM A513. Oval and elliptical sections are manufactured to the mill's own standard. The works is certified to ISO 9001, ISO 14001 and ISO 45001 and CE marked, and every bundle carries a guaranteed tube count.
Specifications
Figures as published in our catalogue. Tolerances are held to the standard named on each table.
BS 1717:1983, BS EN 10305-3:2010 & EN 10296-1:2003 (formerly BS 6323-5:1982)
| OD mm | Per bundle | Wall thickness (mm) | ||||||
|---|---|---|---|---|---|---|---|---|
| 0.6 | 0.7 | 0.9 | 1.0 | 1.2 | 1.6 | 2.0 | ||
| 9.00 | 394 | 0.124 | 0.143 | 0.180 | — | 0.231 | — | — |
| 10.00 | 351 | 0.140 | 0.161 | 0.202 | — | 0.260 | — | — |
| 12.70 | 271 | 0.179 | 0.207 | 0.262 | 0.289 | 0.340 | — | — |
| 15.90 | 271 | 0.226 | 0.262 | 0.333 | 0.367 | 0.435 | 0.564 | 0.686 |
| 16.00 | 200 | — | — | — | — | — | — | 0.691 |
| 17.50 | 271 | — | — | — | — | 0.482 | 0.627 | 0.765 |
| 19.05 | 271 | 0.273 | 0.317 | 0.403 | 0.445 | 0.528 | 0.689 | 0.841 |
| 20.60 | 271 | — | — | — | — | — | 0.750 | 0.917 |
| 22.00 | 217 | — | — | — | — | — | 0.805 | — |
| 22.20 | 217 | — | 0.371 | 0.473 | — | 0.621 | 0.813 | 0.996 |
| 23.80 | 169 | — | — | — | — | — | 0.876 | — |
| 25.40 | 217 | 0.367 | 0.426 | 0.544 | 0.602 | 0.716 | 0.939 | 1.154 |
| 28.60 | 169 | — | — | 0.615 | 0.681 | 0.811 | 1.065 | — |
| 30.00 | 169 | — | — | 0.646 | — | 0.852 | 1.121 | — |
| 31.80 | 169 | — | 0.537 | 0.686 | 0.760 | 0.906 | 1.192 | 1.470 |
| 35.00 | 127 | — | — | — | — | 1.000 | 1.318 | — |
| 38.10 | 91 | — | — | 0.826 | — | 1.092 | 1.440 | — |
| 42.20 | 61 | — | — | 0.917 | — | 1.213 | 1.602 | — |
| 48.10 | 61 | — | — | 1.048 | — | 1.388 | 1.835 | — |
| 60.30 | 61 | — | — | 1.318 | — | 1.749 | — | — |
| 63.50 | 61 | — | — | — | — | 1.844 | 2.442 | — |
| 73.02 | 37 | — | — | — | — | 2.125 | 2.818 | — |
| 75.90 | 37 | — | — | — | — | 2.211 | 2.932 | — |
Outside diameter in mm, figures in kilograms per metre. A dash means that wall is not rolled in that diameter.
BS 6323 Pt 1 & 5, BS 1717, ASTM A513, JIS G3445 STKM
| Outside dia mm | Wall thickness — mass in kg/m | ||||||
|---|---|---|---|---|---|---|---|
| 0.8 | 1.0 | 1.2 | 1.6 | 2.0 | 2.6 | 3.2 | |
| 12.70 | 0.235 | 0.289 | 0.340 | — | — | — | — |
| 15.90 | 0.298 | 0.367 | 0.435 | — | — | — | — |
| 19.05 | 0.360 | 0.445 | 0.528 | 0.689 | — | — | — |
| 22.20 | 0.422 | 0.523 | 0.621 | 0.813 | 0.996 | — | — |
| 25.40 | 0.485 | 0.602 | 0.716 | 0.939 | 1.154 | — | — |
| 31.80 | 0.612 | 0.760 | 0.906 | 1.192 | 1.470 | 1.872 | — |
| 38.10 | 0.736 | 0.915 | 1.092 | 1.440 | 1.780 | 2.276 | 2.754 |
| 44.50 | 0.862 | 1.073 | 1.281 | 1.693 | 2.096 | 2.686 | 3.259 |
| 50.80 | 0.986 | 1.228 | 1.468 | 1.941 | 2.407 | 3.090 | 3.756 |
| 63.50 | 1.237 | 1.541 | 1.844 | 2.442 | 3.033 | 3.905 | 4.758 |
| 76.20 | 1.487 | 1.854 | 2.219 | 2.943 | 3.660 | 4.719 | 5.761 |
Light-wall mechanical and general-engineering tube, quoted on outside diameter. Walls above 3.2 mm are quoted on enquiry.
Made to the mill's own standard
| Size mm | Per bundle | Wall thickness (mm) | |||
|---|---|---|---|---|---|
| 0.90 | 1.20 | 1.60 | 2.00 | ||
| 16 × 30 | 200 | 0.544 | 0.716 | — | — |
| 16 × 40 | 200 | — | 0.906 | 1.192 | 1.470 |
| 30 × 50 | 100 | — | 1.213 | 1.602 | 1.983 |
Section size in mm, figures in kilograms per metre.
Made to the mill's own standard
| Size mm | Per bundle | Wall thickness (mm) | ||
|---|---|---|---|---|
| 0.90 | 1.20 | 1.60 | ||
| 13 × 23 | 200 | 0.403 | 0.528 | 0.689 |
| 19 × 42 | 200 | 0.686 | 0.906 | — |
| 24 × 56 | 100 | — | 1.213 | — |
Section size in mm, figures in kilograms per metre. The 19 × 42 elliptical is also sold in the trade by the 20 ft length — see section 03.
