Product
PSL 1 and PSL 2, Grade B through X60, for oil, gas and water transmission
Line pipe is held to a different standard from general pipe because of what it carries and the pressure it carries it at. API 5L governs the chemistry, the mechanical properties, the weld and the test regime, and the monogram may only be applied by a mill licensed by the American Petroleum Institute to do so.
We manufacture in both product specification levels. PSL 1 is the standard level for water and general transmission duty. PSL 2 carries the same strength floors but adds tighter chemistry limits, guaranteed impact toughness, mandatory non-destructive inspection and stricter documentation — it is what most oil and gas projects specify.
Grades run from Grade B up to X60. The X-number is the specified minimum yield strength in ksi, so X60 pipe is guaranteed to 60,200 psi minimum yield. The full strength table is below.
The certified size range is set by the licence scope rather than by the mill alone, so confirm the sizes and wall thicknesses on your project against our current certificate before specifying.
Specifications
Figures as published in our catalogue. Tolerances are held to the standard named on each table.
API 5L / ISO 3183, PSL 1 and PSL 2
| Grade | Min yield strength | Min tensile strength | ||
|---|---|---|---|---|
| MPa | psi | MPa | psi | |
| Gr. B | 245 | 35,500 | 415 | 60,200 |
| X42 | 290 | 42,100 | 415 | 60,200 |
| X46 | 320 | 46,400 | 435 | 63,100 |
| X52 | 360 | 52,200 | 460 | 66,700 |
| X56 | 390 | 56,600 | 490 | 71,100 |
| X60 | 415 | 60,200 | 520 | 75,400 |
Grade designations are the specified minimum yield strength in ksi. PSL 2 carries the same strength floors as PSL 1 plus tighter chemistry limits, guaranteed impact toughness and mandatory non-destructive inspection — specify which level the project requires.
Gallery
More from the range
Schedule 10, 20, 40 and 80 to ASTM A53, Grade A and Grade B
Electric resistance welded mild steel pipe from 1/2" to 16" diameter in wall thicknesses to 12 mm, hydro-tested and supplied against ASTM A53 and ASME B36.10M in Grade A and Grade B.
Specifications
Square and rectangular ERW pipe in 0.6 mm to 4.0 mm wall
Electric resistance welded square and rectangular mild steel pipe from 10 × 10 mm to 100 × 100 mm and 10 × 20 mm to 60 × 120 mm, in wall thicknesses from 0.6 mm to 4.0 mm with guaranteed square geometry.
Specifications
BS 4568 Class 3 and IS 9537 Part 2 conduit, plus trade weight chart
Electric resistance welded steel conduit manufactured to BS 4568 Class 3 and IS 9537 Part 2, threaded to metric standard, with trade gauge weight charts for 20 ft lengths.
